Two Input One Output Diode Module Din Rail Mounting, Redundant Module “OR”ing Module No of Channel: 1 Channel ( 2 input , 1 output diode module ) Diode Type: Stud mounting (cathode to stud). No. of Diode: Two Input current per Channel: 40 Amp PIV: 1600 VoltTerminal Markings : Output ends are brought to the top row of PCB Mounted terminals marked as K. : Input ends are brought to the top row of PCB Mounted terminals marked as A1, A2. Mounting Type : Panel Mount Brand : Boost Usage/Application : Industrial Part Number : DM-R-40A-16 No. of Diode : 2 PIV : 1600 PIV Input current per Channel : 40Amp Diode Type : Stud mounting (cathode to stud). No of Channel : 1 Country of Origin : Made in India Minimum Order Quantity : 1 Number

Two Input One Output Diode Module Din Rail Mounting, Redundant Module “OR”ing Module No of Channel: 1 Channel ( 2 input , 1 output diode module ) Diode Type: Stud Mounting. No. of Diode: Two Input current per Channel: 10 Amp PIV: 2000 Volt Terminal Connection: Screw terminal, 0.25²mm to 2.5²mm conductor Terminal Markings: Output ends are brought to the top row of PCB Mounted terminals marked as K. : Input ends are brought to the top row of PCB Mounted terminals marked as A1, A2.

One Input One Output Diode Module Din Rail Mounting

8 Channel SSR Module, Coil : 24 V DC, 1 C/O Contact Din Rail Mounting Solderable Relay Operating Temperature : 0 to 50 degree Celsius Storage Temperature : -10 to 60 degree Celsius Relative Humidity : 5 to 85% RH Relay ON Indication : Green Color LED Relay Protection Method : Inbuilt Designation : Designation plate screwed to the PCB for labeling purpose No of Relay Channel : 8 Channel PCB Dimension : 131 mm X 72 mm. Mechanical Dimensions : 133 mm X 90 mm X 66 mm Terminals : Screw type Conductor size : 0.25 -2.5 sq.mm flexible Relay Make / Manufacturer: UNISON Relay Type: 806, PMDD Packaging Details - In corrugated box with bubble sheet.

Din Rail Mounting Power Distribution Module

Power Distribution Module Din Rail Mounting

No of Channel: 1 Channel (2 input, 1 output diode module) Diode Type: Stud Mounting. No. of Diode: Two Input current per Channel: 5 Amp PIV: 1600 Volt Terminal Connection: Screw terminal, 0.25²mm to 2.5²mm conductor Terminal Markings: Output ends are brought to the top row of PCB Mounted terminals marked as K. : Input ends are brought to the top row of PCB Mounted terminals marked as A1, A2. Brand - Boost Usage/Application - Industrial Part Number- DM-R-5A-16 Size - 70 mm X 90 mm X 115 mm PCB Material - FR4, Glass Epoxy Country of Origin - Made in India Minimum Order Quantity - 1

Two Input One Output Diode Module Din Rail Mounting “OR” ing Module Operating Temperature : 0 to 50 degree Celsius Storage Temperature : -10 to 60 degree Celsius Relative Humidity : 5 to 85% RH Designation : Designation plate screwed to the Backelite for labeling purpose No of Channel : 1 Channel (2 input, 1 output diode module) Diode Type : Stud mounting (cathode to stud) No. of Diode : 2 PIV : 1600 Volt Conductor Size : Screw terminal 4 mm² to 25 mm² Mounting Type : Din rail Mountable Size : 110 mm X 150 mm X 140 mm Testing Visual Inspection : 100 %. Dimensional Check : 100 %. Diode Polarity Test : 100 % Continuity Test : 100 %.

No of Relay Channel: 1 Channel ( 2 input , 1 output diode module ) Diode Type: Stud Mounting. No. of Diode: Two Coil Voltage: 230 V AC. Input current per Channel: 20 Amp PIV: 1600 Volt Terminal Connection: Screw terminal, 0.25²mm to 2.5²mm conductor Terminal Markings: Output ends are brought to the top row of PCB Mounted terminals marked as K. : Input ends are brought to the top row of PCB Mounted terminals marked as A1, A2.
