relay interfacing module

Din Rail Mounting Plug-gable Relay 20,000,000 Mechanical operations minimum. 50,000 Electrical operations minimum. Operating Temperature: 0 to 50 degree Celsius. Storage Temperature: -10 to 60 degree Celsius. Relative Humidity: 5 to 85% RH Relay ON Indication: Green color LED. Relay Protection Method: Freewheeling Diode. Designation: Designation plate screwed to the PCB for Labeling purpose.

Ordering Type : RP230A08-1CO-M Din Rail Mounting Solderable Relay 10,000,000 Mechanical operations minimum. 50,000 Electrical operations minimum. Operating Temperature : 0 to 50 degree Celsius Storage Temperature : -10 to 60 degree Celsius Relative Humidity : 5 to 95 % RH Relay ON Indication : Green color LED Relay Protection Method : NA Designation : Designation plate screwed to the PCB for labeling purpose

Operating Temperature: 0 to 50 degree Celsius Storage Temperature: -10 to 60 degree Celsius Relative Humidity: 5 to 95% RH Relay ON Indication: Green Color Led Relay Protection Method: Freewheeling Diode Fuse Link: A glass fuse link provided at pole of each Relay Fuse Blow Indication: Each Fuse in path of pole is provided with red LED indicates Fuse Blown Indication Fuse Rating: 5 Ampere Designation: Designation plate screwed to the PCB for labeling

No of Relay Channel: 1 Channel. Rating of Contacts: 3 Amp at 24 V DC & 220 V AC for Resistive load. Coil Resistance: 18,790 Ohms +/-10%. Coil Voltage: 230 V AC. Relay Socket: Rating- 5 A, 250 V AC. Operating Voltage: 230 V AC ±10%. Input Current/ Channel: 13 mA at 230 Volt AC Terminals: Screw type. Conductor size: 0.25 -2.5 sq.mm flexible. Relay Make / Manufacturer: OMRON. Relay Type: Electro-mechanical, MY4 Contact Type: 4 Change Over.

Operating Temperature: 0 to 50 degree Celsius Storage Temperature: -10 to 60 degree Celsius Relative Humidity: 5 to 95% RH Relay ON Indication: Green Color Led Relay Protection Method: Freewheeling Diode Dimensions PCB Dimension: 90 mm x 72 mm. Mechanical Dimensions: 92 mm X 90 mm X 68 mm Operating Voltage: 230 V AC ±10%. Input Current/ Channel : 12 mA at 230 Volt AC Terminals: Screw type. Conductor size: 0.25 -2.5 sq.mm flexible. Relay Make / Manufacturer: OMRON. Relay Type: Electro-mechanical, G2R-2 Contact Type: 2 Change Over. Designation: Designation plate screwed to the PCB for labeling purpose. No of Relay Channel: 4 Channels. Rating of Contacts: 5 Amp at 30 V DC & 240 V AC for Resistive load. Coil Resistance: 20,000 Ohms +/-10%. Coil Voltage: 230 V AC. Relay Socket: Rating- 5 A, 250 V AC.

Product Name: Relay Module Operating Temperature : 0 to 50 degree Celsius. Storage Temperature : 10 to 60 degree Celsius. Relative Humidity : 5 to 85% RH. Relay ON Indication : Green color LED. Relay Protection Method : Freewheeling Diode Designation :Designation plate screwed to the PCB for labeling purpose. Rating of Contacts : 5 Amp at 24 V DC & 230 V AC for Resistive load. Coil Resistance : 662 Ohms. Conductor size : 0.25 to 2.5 sq.mm flexible. Relay Make / Manufacturer : OMRON

Operating Temperature : 0 to 50 degree Celsius Storage Temperature: 10 to 60 degree Celsius Relative Humidity : 5 to 95% RH Relay ON Indication: Green Color Led Relay Protection Method: Freewheeling Diode Designation: Designation plate screwed to the PCB for labeling purpose. Rating of Contacts: 10 Amp at 30 V DC & 250 V AC for Resistive load. Coil Resistance: 1100 Ohms +/-10%. Coil Voltage: 24 V DC Relay Socket: Rating- 5 A, 250 V AC.

Operating Temperature : 0 to 50 degree Celsius Storage Temperature : 10 to 60 degree Celsius Relative Humidity : 5 to 95% RH Relay ON Indication : Green Color Led Relay Protection Method : Freewheeling Diode Designation : Designation plate screwed to the PCB for labeling purpose. Rating of Contacts : 5 Amp at 0-230 V AC Input Voltage : 4-32 V DC Relay Socket : 5 A, 230 V AC Terminals : Screw type. Conductor size : 0.25 -2.5 sq.mm flexible. Relay Make / Manufacturer : Unison Relay Type : USSR 806 PMDD

Terminals : Screw type. Conductor size : 0.25 to 2.5 sq.mm flexible. Relay Make / Manufacturer : OMRON. Relay Type : MY2, Electro-mechanical. Contact Type : 2 Change Over No of Relay Channel : 04 Channel. Rating of Contacts : 5 Amp at 24 V DC & 230 V AC for Resistive load. Coil Resistance : 662 Ohms. Coil Voltage : 24 V DC Operating Temperature : 0 to 50 degree Celsius. Storage Temperature : 10 to 60 degree Celsius. Relative Humidity : 5 to 85% RH. Relay ON Indication : Green color LED. Relay Protection Method : Freewheeling Diode Designation :Designation plate screwed to the PCB for labeling purpose

Relays (Standard/Approvals) : 1. CSA Certified, 2. UL Recognized 3. EN, Certified 4. CE, Certified Terminals (Standard/Approvals) : 1.EN, Certified. 2. UL Canadian Approval 3. RoHS COC 4. CE Approval by UL1 5. NO CE Third Party Witness Testing

Operating Temperature: 0 to 50 degree Celsius Storage Temperature: 10 to 60 degree Celsius Relative Humidity : 5 to 95% RH Relay ON Indication: Green Color Led Relay Protection Method: Freewheeling Diode Designation: Designation plate screwed to the PCB for labeling purpose Rating of Contacts: 10 Amp at 30 V DC & 250 V AC for Resistive load. Coil Resistance: 1440 Ohms +/- 10%. Input Current/ Channel:12 mA @ 24 V DC. Terminals: Screw type. Conductor size : 0.25 -2.5 sq.mm flexible. Relay Make / Manufacturer: OMRON. Contact Type: 1 Change Over.

Operating Temperature : 0 to 50 degree Celsius Storage Temperature : 10 to 60 degree Celsius Relative Humidity : 5 to 95% RH Relay ON Indication : Green Color Led Relay Protection Method : Freewheeling Diode Fuse Link : A glass fuse link provided at pole of each Relay. Fuse Rating : 5 Ampere Designation : Designation plate screwed to the PCB for labeling purpose. Contact Type : 1 Change Over.
