relay interfacing module

Din Rail Mounting Solderable Relay 20,000,000 Mechanical operations minimum. 30,000 Electrical operations minimum Operating Temperature : 0 to 50 degree Celsius Storage Temperature : -10 to 60 degree Celsius Relative Humidity : 5 to 85% RH Relay ON Indication : Green Color LED Relay Protection Method : Freewheeling Diode Designation : Designation plate screwed to the PCB for labeling purpose

Din Rail Mounting Solderable Relay 20,000,000 Mechanical operations minimum. 30,000 Electrical operations minimum. Operating Temperature: 0 to 50 degree Celsius Storage Temperature: -10 to 60 degree Celsius Relative Humidity: 5 to 85% RH Relay ON Indication: Green Color LED Relay Protection Method: Freewheeling Diode Designation: Designation plate screwed to the PCB for labeling purpose.

Din Rail Mounting Pluggable Relay 100,000,000 Mechanical operations minimum. 500,000 Electrical operations minimum. Operating Temperature: 0 to 50 degree Celsius Storage Temperature: -10 to 60 degree Celsius Relative Humidity: 5 to 85% RH Relay ON Indication: Green Color LED Relay Protection Method: Freewheeling Diode Designation : Designation plate screwed to the PCB for labeling purpose

Din Rail Mounting Pluggable Relay 20,000,000 Mechanical operations minimum. 30,000 Electrical operations minimum. Operating Temperature: 0 to 50 degree Celsius Storage Temperature: -10 to 60 degree Celsius Relative Humidity: 5 to 85% RH Relay ON Indication: Green Color LED Relay Protection Method: Freewheeling Diode Designation: Designation plate screwed to the PCB for labeling purpose

Din Rail Mounting Pluggable Relay 20,000,000 Mechanical operations minimum. 30,000 Electrical operations minimum.

Din Rail Mounting Pluggable Relay 20,000,000 Mechanical operations minimum. 30,000 Electrical operations minimum.

Din Rail Mounting Pluggable Relay 10,000,000 Mechanical operations minimum. 100,000 Electrical operations minimum.

Din Rail Mounting Solderable Relay 20,000,000 Mechanical operations minimum. 1,00,000 Electrical operations minimum.

Operating Temperature: 0 to 50 degree Celsius Storage Temperature: -10 to 60 degree Celsius Relative Humidity: 5 to 95% RH Relay ON Indication: Green Color LED Relay Protection Method: Freewheeling Diode Designation: Designation plate screwed to the PCB for labeling purpose

Din Rail Mounting Pluggable Relay 10,000,000 Mechanical operations minimum. 100,000 Electrical operations minimum. Operating Temperature: 0 to 50 degree Celsius Storage Temperature : -10 to 60 degree Celsius Relative Humidity: 5 to 95% RH Relay ON Indication: Green Color LED Relay Protection Method: NA Designation: Designation plate screwed to the PCB for labeling purpose

Din Rail Mounting Pluggable Relay 100,000,000 Mechanical operations minimum. 200,000 Electrical operations minimum. Operating Temperature : 0 to 50 degree Celsius. Storage Temperature: -10 to 60 degree Celsius. Relative Humidity : 5 to 85% RH. Relay ON Indication : Green color LED. Designation: Designation plate screwed to the PCB for Labeling purpose.

Din Rail Mounting Pluggable Relay 100,000,000 Mechanical operations minimum. 200,000 Electrical operations minimum. Relays (Standard/Approvals) : CSA Certified : UL Recognized. : EN, TUV Certified. Terminals (Standard/Approvals) : EN, TUV Certified : UL Canadian Approval. : RoHS COC. : CE Approval by UL1. : NO CE Third Party Witness Testing.
