Relay Interfacing Module by Boost Electronics

Relay Interfacing Module RP24D08-4CO-M-B14/P

Phone Number

08048036394

Please keep 0 before dialling the number.

Email Address info@boostelectronics.com

Mon-Thu: 10 AM - 2 PM • Fri: 3 PM - 7AM

Other Website Visit our other website

Address Office : Ground Floor, Vivek Bungalow, Kulkarni Colony, Nasik – 422 002 Maharashtra Factory : S-29, MIDC Ambad, Nasik – 422 010, Maharashtra, India

Nashik, India, 422002

Description

Din Rail Mounting Pluggable Relay 100,000,000 Mechanical operations minimum. 200,000 Electrical operations minimum. Relays (Standard/Approvals) : CSA Certified : UL Recognized. : EN, TUV Certified. Terminals (Standard/Approvals) : EN, TUV Certified : UL Canadian Approval. : RoHS COC. : CE Approval by UL1. : NO CE Third Party Witness Testing.

Specifications

No of Relay Channel	08
Rating of Contacts	3 Amp at 24 V DC & 220 V AC for Resistive loads.
Contact Type	4 Change over
Coil Resistance	662 Ohms ±10%
Coil Voltage	24 V DC
Relay Socket	5 Amp, 250 V AC
Input Current/ Channel	36 mA @ 24 V DC
Mechanical Dimensions	360 mm X 90 mm X 83 mm
Terminals	Screw type
Conductor size	0.25 to 2.5 sq. mm flexible.
Relay Make / Manufacturer	OMRON
Relay Type	MY4, Electro-mechanical
Contact Type	4 Change over
