Relay Interfacing Module RP24D04-2CO- M-B8/P
In stock
Description
Product Name: Relay Module
Product Code: RP24D04-2CO- M-B8/P
No of Relay Channel : 04 Channel
Rating of Contacts : 8 Amp at 30 V DC & 250 V AC for Resistive load
Coil Resistance : 2,304 Ohms +/-10%
Coil Voltage : 24 V DC Relay socket : 5 A, 250 V AC
Relay Make / Manufacturer : OMRON.
Relay Type : Electro-mechanical, G2RL-2
Contact Type : 2 Change Over.
Operating Temperature : 0 to 50 degree Celsius
Storage Temperature : 10 to 60 degree Celsius
Relative Humidity : 5 to 95% RH
Relay ON Indication : Green Color Led Relay
Protection Method : Freewheeling Diode
Specifications
| Item/ Model No | RP24D04-2CO- M-B8/P |
|---|---|
| Operating Temperature | 0 to 50 degree Celsius |
| Relay Type | Electro-mechanical, G2RL-2 |
| Contact Type | 2 Change Over. |
| Relay Make / Manufacturer | OMRON |
| Relay ON Indication | Green Color Led Relay |
| No of Relay Channel | 04 |
