Terminals : Screw type.
Conductor size : 0.25 to 2.5 sq.mm flexible.
Relay Make / Manufacturer : OMRON.
Relay Type : MY2, Electro-mechanical.
Contact Type : 2 Change Over
No of Relay Channel : 04 Channel.
Rating of Contacts : 5 Amp at 24 V DC & 230 V AC for Resistive load.
Coil Resistance : 662 Ohms.
Coil Voltage : 24 V DC
Operating Temperature : 0 to 50 degree Celsius.
Storage Temperature : 10 to 60 degree Celsius.
Relative Humidity : 5 to 85% RH.
Relay ON Indication : Green color LED.
Relay Protection Method : Freewheeling Diode
Designation :Designation plate screwed to the PCB for labeling purpose
Specifications
| Model Name/Number |
RP24D04-2CO-M-B8/P(MY2) |
| Usage/Application |
Industrial |
| Country of Origin |
Made in India |
| Channels |
04 |
| Relay Manufacturer |
OMRON |
