Din Rail Mounting
Pluggable Relay
20,000,000 Mechanical operations minimum.
30,000 Electrical operations minimum.
Specifications
| No of Relay Channel |
02 |
| Rating of Contacts |
10 A at 24V DC and 250V AC For resistive load |
| Contact Type |
1 Change Over |
| Coil Resistance |
1,440 Ohms + 10%. |
| Coil Voltage |
24 V DC |
| Relay Socket |
5 A, 250 V AC |
| Input Current/ Channel |
17 mA per channel |
| Mechanical Dimensions |
55 mm X 90 mm X 66 mm |
| Terminals |
Screw type |
| Conductor size |
0.25 -2.5 sq.mm flexible |
| Relay Make / Manufacturer |
OMRON |
| Relay Type |
G2RL-1, Electro-mechanical |
| Contact Type |
1 Change Over |
