Din Rail Mounting
Pluggable Relay
10,000,000 Mechanical operations minimum.
100,000 Electrical operations minimum.
Operating Temperature : 0 to 50 degree Celsius
Storage Temperature : -10 to 60 degree Celsius
Relative Humidity : 5 to 85% RH
Relay ON Indication : Green Color LED
Relay Protection Method : NA
Designation : Designation plate screwed to the PCB for labeling purpose
No of Relay Channel : 16 Channel
Rating of Contacts : 10 A at 30V DC and 250V AC for resistive load.
Coil Resistance : 4600 Ohms + 10%.
Coil Voltage : 110 V AC
Relay Socket : 5 A, 250 V AC
Input Current/ Channel : 24 mA per channel
| Contact Type |
01 Change Over |
| Relay Type |
G2R-1, Electro-mechanical |
| Relay Make / Manufacturer |
OMRON |
| Conductor size |
0.25 -2.5 sq.mm flexible |
| Terminals |
Screw type |
| Mechanical Dimensions |
248 mm X 90 mm X 66 mm |
| Input Current/ Channel |
24 mA per channel |
