8 Channel SSR Module, Coil : 24 V DC, 1 C/O Contact Din Rail Mounting Solderable Relay Operating Temperature : 0 to 50 degree Celsius Storage Temperature : -10 to 60 degree Celsius Relative Humidity : 5 to 85% RH Relay ON Indication : Green Color LED Relay Protection Method : Inbuilt Designation : Designation plate screwed to the PCB for labeling purpose No of Relay Channel : 8 Channel PCB Dimension : 131 mm X 72 mm. Mechanical Dimensions : 133 mm X 90 mm X 66 mm Terminals : Screw type Conductor size : 0.25 -2.5 sq.mm flexible Relay Make / Manufacturer: UNISON Relay Type: 806, PMDD Packaging Details - In corrugated box with bubble sheet.

Operating Temperature : 0 to 50 degree Celsius Storage Temperature : 10 to 60 degree Celsius Relative Humidity : 5 to 95% RH Relay ON Indication : Green Color Led Relay Protection Method : Freewheeling Diode Designation : Designation plate screwed to the PCB for labeling purpose. Rating of Contacts : 5 Amp at 0-230 V AC Input Voltage : 4-32 V DC Relay Socket : 5 A, 230 V AC Terminals : Screw type. Conductor size : 0.25 -2.5 sq.mm flexible. Relay Make / Manufacturer : Unison Relay Type : USSR 806 PMDD
